AMD Ryzen 9 9950X3D 16xCore, 4.3 GHz/5.7 GHz – BOX

AMD Ryzen™ 9 9950X3D – High-Performance Enthusiast Desktop Processor

• Architecture: Zen 5

• Cores / Threads: 16 Cores / 32 Threads

• Base Clock: 4.3 GHz

• Max. Boost Clock: Up to 5.7 GHz

• L1 Cache: 1280 KB

• L2 Cache: 16 MB

• L3 Cache: 128 MB

• TDP: 170W

• CPU Socket: AM5

• Supporting Chipsets: A620, X670E, X670, B650E, B650, X870E, X870, B840, B850

Key Features and Benefits:

• Processor Technology: Crafted with TSMC 4nm FinFET for the CPU cores and TSMC 6nm FinFET for the I/O die, delivering unparalleled performance and efficiency.

• Unlocked for Overclocking: Yes, offering the flexibility for enthusiasts to maximize performance.

• AMD EXPO™ Memory Overclocking Technology: Yes, for exceptional memory speed and stability.

• Precision Boost Overdrive & Curve Optimizer: Yes, allowing dynamic adjustments and fine-tuning for optimal results.

• AMD Ryzen™ Master Support: Yes, for easy overclocking and system monitoring.

• Max. Operating Temperature: 95°C

• Thermal Solution: Not included – a liquid cooler is recommended to ensure optimal performance.

Memory Support:

• System Memory Type: DDR5 (UDIMM)

• Memory Channels: 2

• Max. Memory Capacity: 192 GB

• Supported Speeds:

  • 2x1R: DDR5-5600

  • 2x2R: DDR5-5600

  • 4x1R: DDR5-3600

  • 4x2R: DDR5-3600

• ECC Support: Yes (Requires motherboard support)

Connectivity & Expansion:

• PCIe Version: PCIe® 5.0 for lightning-fast data transfer speeds.

• Native PCIe® Lanes (Total/Usable): 28 / 24

• USB Ports: 4x USB 3.2 Gen 2 (10Gbps), 1x USB 2.0 (480Mbps)

• NVMe Support: Boot, RAID 0, RAID 1, RAID 5, RAID 10

Operating System Support:

• Windows 11 – 64-Bit Edition

• Windows 10 – 64-Bit Edition

• RHEL x86 64-Bit

• Ubuntu x86 64-Bit

Launch Date: December 3, 2025
