Gigabyte AMD Radeon RX 9070 XT Gaming OC 16GB GDDR6

AMD Radeon™ RX 9070 XT – High-Performance Gaming with Advanced Cooling

Next-Generation Graphics for Gamers and Creators

Unleash cutting-edge gaming power with the AMD Radeon™ RX 9070 XT. Engineered for high-performance 4K gaming, this GPU is powered by 4096 stream processors and 16GB of GDDR6 memory, delivering ultra-fast speeds and exceptional visual fidelity. With boost clocks reaching up to 3060 MHz, the RX 9070 XT offers smooth gameplay and superior performance for the most demanding games and applications.

Core Specifications

Graphics Engine: Radeon™ RX 9070 XT
Stream Processors: 4096
Boost Clock: Up to 3060 MHz (Reference: 2970 MHz)
Game Clock: Up to 2520 MHz (Reference: 2400 MHz)
Memory Size: 16GB GDDR6
Memory Bus: 256-bit
Memory Clock: 20 Gbps
Bus Interface: PCI-E 5.0

Unparalleled Display & Connectivity

Maximum Digital Resolution: 7680×4320
Multi-View Support: Up to 4 Displays
Output Ports:

• 2 x DisplayPort 2.1a – Ultra-high refresh rates for immersive gaming

• 2 x HDMI 2.1b – Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate

Advanced Cooling for Maximum Performance

• WINDFORCE Cooling System – Optimized airflow for superior thermal management

• Hawk Fan Technology – High-efficiency cooling with whisper-quiet operation

• Server-Grade Thermal Conductive Gel – Improved heat dissipation for extended durability

• Dual BIOS (Performance/Silent Mode) – Choose between high performance or quiet operation

• Reinforced Structure – Enhanced durability and stability

Power & System Requirements

• Power Connectors: 3 x 8-Pin

• Recommended PSU: 850W

• Card Dimensions: 288mm (L) x 132mm (W) x 56mm (H)

• PCB Form Factor: ATX
